LX Eco - Wheel Balancer
Lx Eco - Wheel Balancing Machine
Wheel balancing machines are essential equipment used to ensure the balance of car wheels and rims. These machines enhance driving comfort by ensuring tires rotate smoothly and evenly, thereby extending the life of wheels and rims. Additionally, a balanced wheel-rim combination improves vehicle performance and optimizes fuel efficiency.
Our Lx/Eco wheel balancing machine is a price/performance product. Lx/Eco, like all our wheel balancing machines, offers special programs that store different wheel measurement data, providing suitability for various user needs. Features such as special programs for aluminum wheels or programs for concealing lead division and wheel arms behind specially developed for multi-spoke aluminum wheels offer operators a wide range of operations.
- 19" LCD screen
- Easy operation via multi-functional symbols and keypad
- Automatic start controlled by hood switch
- Automatic positioning of outer surface unbalance point after rotation
- Automatic positioning of inner surface unbalance point with a single button
- Special 4-user program capable of storing information for 4 different wheel measurements
- Special program for concealing lead division and wheel arms for multi-spoke aluminum wheels
- Optimization program for compensating imbalance between wheel and tire
- Lx/Eco Air Lock (optional)
- Cone No. 1-2 combined
- Cone No. 3-4
- Clamping Sleeve
- Plier
- 2 Pieces universal Ford cone
- 5 Wheel bolt apparatus (for rims with closed hub)
- Airlock - Mechanical with air tightening
- Touchscreen
Technical Specifications
Downloads
Videos
More Information
| Technical Specifications | Unit | Pro/S Plus | Pro/S | Pro/Eco | Lx/Eco | Raptor | Hector | Sirion Truck |
| Vehicle Type | Passenger and light commercial vehicles | Passenger and light commercial vehicles | Passenger and light commercial vehicles | Passenger and light commercial vehicles | Passenger and light commercial vehicles | Passenger and light commercial vehicles | Truck, passenger and light commercial vehicles | |
| Max. Wheel Weight | kg | 75 | 75 | 70 | 65 | 75 | 65 | 250 |
| Max. Wheel Diameter | inch | 40" | 40" | 40" | 40" | 40" | 40" | 1300 mm |
| Rim Diameter | inch | 10" - 30" | 10" - 30" | 10" - 30" | 10" - 30" | 10" - 30" | 10" - 30" | 10" - 30" |
| Rim Width | inch | 1.5" - 20" | 1.5" - 20" | 1.5" - 20" | 1.5" - 20" | 1.5" - 20" | 1.5" - 20" | 1.5" - 20" |
| Cycle Time | sec. | 6 | 6 | 8 | 8 | 6 | 8 | 8 - 20 |
| Rotation Speed | rpm | 120 | 120 | 120 | 120 | 120 | 120 | 150 rpm (passenger cars) - 80 rpm (trucks) |
| Sensitivity | gr | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Power | 230/1 50/60 Hz. | 230/1 50/60 Hz. | 230/1 50/60 Hz. | 230/1 50/60 Hz. | 230/1 50/60 Hz. | 230/1 50/60 Hz. | 230/1 50/60 Hz. | |
| Air Pressure | bar | Optional 8 Bar | Optional 8 Bar | Optional 8 Bar | Optional 8 Bar | Optional 8 Bar | Optional 8 Bar | Optional 8 - 10 Bar |
